Compact Pro Turret seat
The unique design of the Mobius Turret Seat product line is tailored to accommodate the varying needs of the occupants – the commander, gunner, and loader – given the spatial constraints of the turret, the multiuse of the space, and the varied driving, environmental, and operational conditions
INNOVATIVE
Mounting Options
Attached to turret structure (flexible positioning)
Seats supplied with a designated bracket
Seat Belt
A 3, 4, or 5-point seatbelt.
With or without inertia reels
Adjustments
Height Adjustment
Multiple folding positions to support sitting and standing
Energy Absorption
The linear EA is a single element wall system, with a compact design and low weight. Typically located under a hatch, it is highly resilient to humidity, solar radiation and dirt
Ergonomics
Ergonomically designed to maximize comfort, even during extended periods of time
Gunner/Commander Turret seats
Given the space constraints of the turret, the multiuse of the area, and the diverse driving, environmental, and operating situations, the Mobius Turret Seat product line's distinctive design is geared to satisfy the varying demands of the occupants - the commander, gunner, and loader
Dimensions
Weight
30 kg
Height adjustment
250 mm
Fore-aft adjustment
N/A
Adjusmnets
Ergonomics
Ergonomic design suitable for 5th to 95th percentile
Mounting options
Attached to turret structure (flexible positioning)
Seats supplied with a designated bracket
Additional adjustment options
Folding back and folding Pan
Safety
Energy absorption
SPIRAL Energy Absorption system
Safety
Designed to meet automotive regulations, including flammability regulations FMVSS 302
Designed to meet FMVSS 207/210
Designed to meet ECE R14
Seat belts
A 3, 4, or 5-point seatbelt.
With or without inertia reels
